ROPE

  • Bare and tinned copper
  • Nominal sections 16 – 25 – 35 – 50 – 70 – 95 – 120 mm2

PACKAGING

  • Reels diameters 1000 – 1250 mm
  • Concentric and unilay flexible ropes on request

PRODUCTION RANGE

FLEXIBLE ROPES CLASS 5
Section mm2 Construction
Bare Copper
25 ((6 x 26) + (27)) x 0,40 – 183 x 0,40
35 (7 x 37) x 0,40 – 259 x 0,40
50 ((4 x 54) + (3 x 52)) x 0,40 – 372 x 0,40
70 (19 x 28) x 0,40 – 532 x 0,40 (7 x 80) x 0,40 – 560 x 0,40
95 ((18 x 36) + (42)) x 0,40 – 690 x 0,40 ((7 x 40) + (12 x 36)) x 0,40 – 712 x 0,40
120 ((7 x 52) + (12 x 48)) x 0,40 – 940 x 0,40

Packaging

= DIN 1000 – DIN 1200

EXTRAFLEXIBLE ROPES CLASS 6
Section mm2 Construction
Bare Copper
16 (7 x 72) x 0,203 – 504 x 0,20
25 (7 x 112) x 0,203 – 784 x 0,20
35 (19 x 60) x 0,203 – 1140 x 0,20 (19 x 57) x 0,203 – 1083 x 0,20
50 (19 x 80) x 0,203 – 1520 x 0,20
70 (19 x 112) x 0,203 – 2128 x 0,20
95 (19 x 150) x 0,203 – 2850 x 0,20
120 (37 x 99) x 0,203 – 3663 x 0,20

Packaging

= DIN 1000 – DIN 1200
